Tesnit Style Armit CAF
is a Compressed Asbestos Fiber (CAF) gasket material reinforced with steel wire (wire-reinforced).
This material is specifically engineered by Donit Tesnit for extreme applications involving high pressure and fluctuating high temperatures.
Key Features
- Wire Reinforcement: Uses woven carbon steel wire to enhance mechanical strength against internal pressure and dynamic loads.
- Temperature & Pressure Resistance: Capable of handling pressures up to 200 bar and peak temperatures up to 550°C – 600°C.
- Composition: Made from asbestos fibers combined with NBR (Nitrile Butadiene Rubber) binder and coated with graphite to facilitate easy gasket removal.
Applications
This material is highly suitable for harsh industrial environments, such as:
- Media: Oil, fuel, lubricants, solvents, steam, water, air, and various gases.
- Industries: Commonly used in machinery manufacturing, automotive, shipbuilding, and high-pressure steam piping installations.
General Technical Specifications
|
Parameter
|
Estimated Value
|
|
Color
|
Grey
|
|
Maximum Temperature
|
550°C – 600°C
|
|
Maximum Pressure
|
200 bar (some variants up to 300–1000 bar)
|
|
Available Thickness
|
1.0 mm, 1.5 mm, 2.0 mm, up to 3.0 mm
|
|
Sheet Size
|
Commonly 1500 × 2000 mm or 1000 × 1500 mm
|
