Teadit Style NA-1005 is a versatile compressed non-asbestos fiber (CNAF) gasket material made from a blend of aramid fibers and other synthetic fibers, bonded with Nitrile Rubber (NBR).
Main Technical Specifications
Technical Specifications
- Base Material: Aramid fibers with NBR binder
- Standard Color: Blue (other colors available upon request)
Temperature Range:
- Continuous Operating Temperature: up to +240°C
- Peak (Maximum) Temperature: up to +400°C
Pressure Rating:
- Continuous Working Pressure: 50 bar
- Peak Pressure: 110 bar
Applications and Uses
This material is designed to handle a wide range of industrial media, including:
- Air, water, and seawater
- Low-pressure steam
- Petroleum derivatives, synthetic oils, and vegetable oils
- Weak organic and inorganic acids, as well as alkalis
- Refrigerants and various common industrial gases
Product Availability
- Thickness Range: 0.5 mm to 3.0 mm
- Sheet Sizes: Commonly available in 1,500 × 1,600 mm or 1,500 × 3,200 mm
- Certifications: Manufactured in accordance with ISO 9001, approved by ABS (American Bureau of Shipping), and fire-safe compliant with ISO 19921
